HMS Holland 1 |
Robert Edmonds Collection |
|
Page 2 |
 |
May 13, 2008: The torpedo tube of the Holland 1.
|
 |
May 13, 2008: The torpedo tube inside the Holland 1.
|
 |
May 13, 2008: The torpedo tube inside the Holland 1.
|
 |
May 13, 2008: The 160 HP main gasoline engine on the Holland 1.
|
 |
May 13, 2008: Looking forward on the starboard side of the main engine.
|
 |
May 13, 2008: At left the 70 HP electric motor used for underwater propulsion, at right the gears attached to the single shaft. The levers in the foreground are used to change power sources and the cage at the top held mice which were used to detect gasoline (petrol) fumes. |
(All photos courtesy of Robert Edmonds)
|
